Biaxial Fiberglass Fabric Cloth is a two-layer fiberglass reinforcement, with fibers oriented in either ±45° (BX) or 0°/90° (LT) directions. The layers are stitched together using polyester yarn, ensuring structural stability and excellent drapability. These fabrics provide enhanced strength and stiffness along two principal axes, making them ideal for structural applications. They can also be combined with a chopped strand mat layer for improved resin distribution.
Swipe or wait — images change automatically.
| Specification | Total weight (gsm) | 45°Degree(gsm) | -45°Degree(gsm) | CSM(gsm) | Stitching Yarn(gsm) |
| BXM600/225 | 832 | 300 | 300 | 225 | 7 |
| Specification | Total weight (gsm) | Deviation (%) | 0°Degree(gsm) | 90°Degree(gsm) | Stitched Yarn(gsm) |
| LT600 | 610 | ±7 | 336 | 264 | 10 |
| LT800 | 810 | ±7 | 336 | 464 | 10 |
| LT600 | 610 | ±7 | 420 | 180 | 10 |
| LT800 | 810 | ±7 | 420 | 380 | 10 |
| LT1000 | 1110 | ±7 | 672 | 328 | 10 |
| LT1200 | 1510 | ±7 | 672 | 528 | 10 |
One roll is wrapped in plastic film and then placed into a carton or a large carton.
Normally, P4 (4 big rolls) or P7 (4 big rolls + 3 small rolls) or 6, 9, or 12 small rolls are packed per pallet horizontally/vertically. It can be customized based on the loading method.
Fiberglass products should be stocked in a dry, cool, and waterproof place. The best condition is with a temperature between 15-35℃, with a relative humidity between 30%-65%. Please keep the product in its original packaging before use, avoiding moisture.
Weitong currently operates over 30 fiberglass weaving machines for producing woven roving, along with various other equipment, including stitched mat machines, multiaxial tricot machines, PP core mat machines, and carding machines. Our annual production capacity reaches 3,000 tons of woven roving, 5,000 tons of stitched mat, 10,000 tons of multiaxial fabrics, 8,000 tons of combo mat, and 2,000 tons of RTM core mat.
Our team has already attended the China(Shanghai) International Composite Exhibition for 9 years, and JEC France, Composites Europe, and JEC Asia several times in France, Germany and Korea.
Backed by a highly skilled team of professional technicians, we have strong capabilities in developing and customizing specialized products to meet diverse customer requirements.
